ABB 3BHE023784R2530 / PPD113B01-25-111000

PLC/DCS Module for Chemical Industry – English Product Introduction

Product Overview

3BHE023784R2530 (PPD113B01-25-111000) is a high-performance, redundant power supply & control module designed by ABB for the AC 800PEC / Symphony Plus DCS/PLC platforms, widely deployed in chemical, petrochemical, refining, and pharmaceutical industries. It serves as both a system power backbone and a process control I/O combi module, ensuring stable power distribution, precise signal conditioning, and reliable closed‑loop control under corrosive, humid, and explosive hazardous‑area conditions.

Key Features

1. Industrial‑Grade Redundant Power
   • Input: 100–240 VAC, 50/60 Hz (auto‑ranging)
   • Output: 24 VDC / 25 W, with 1:1 or 1:2 redundancy
   • Hot‑swap capable: replace online without shutdown for 24/7 continuous production
   • High efficiency (>85%) + convection cooling; overvoltage/overcurrent/short‑circuit/overtemperature protection
2. Integrated Combi I/O & Control
   • Combines analog/digital I/O + power distribution + control logic in one unit
   • Supports up to 8 analog inputs, 16 digital inputs, 16 digital outputs, 4 relay outputs
   • 16‑bit precision, ±0.1% FS accuracy; accepts 4–20 mA / 0–10 V standard signals
3. Harsh Environment Adaptability
   • Operating temperature: ‑20°C to +60°C (extended: ‑40°C to +70°C)
   • Conformal coating on PCBs to resist chemical vapors, dust, and moisture
   • Compliant with IEC 61000 (EMC), CE/UL/CSA/RoHS; IP20 protection
4. Flexible Communication & System Compatibility
   • Protocols: Modbus TCP/RTU, Profibus DP, EtherNet/IP, AnyIO (×2)
   • Seamless integration with ABB AC 800PEC, Symphony Plus, Advant 800xA and third‑party SCADA/MES

Typical Applications

• Chemical reactors: precise temperature/pressure/flow control & interlocking
• Distillation columns: level, composition, and flow monitoring + valve sequencing
• Hazardous zones: power supply + signal acquisition in explosive/corrosive areas
• Utilities: boilers, circulating water, wastewater treatment automation
• Critical machinery: pumps, compressors, turbines condition monitoring & control

Technical Specifications

• Part Number: 3BHE023784R2530
• Model: PPD113B01-25-111000
• Type: Redundant Power Supply + Combi I/O Controller
• Power Input: 100–240 VAC, 50/60 Hz
• Power Output: 24 VDC, 25 W, redundant
• I/O Channels: 8 AI / 16 DI / 16 DO / 4 Relay
• Resolution: 16 bit; Accuracy: ±0.1% FS
• Operating Temp: ‑20°C ~ +60°C (‑40°C ~ +70°C optional)
• Mounting: 35 mm DIN rail or standard rack
• Protection: Overvoltage, overcurrent, short‑circuit, overtemperature
• Certification: CE, UL, CSA, RoHS, IEC 61508 (SIL capable)

Product Advantages

• All‑in‑one design: power + I/O + control reduces cabinet space and wiring complexity
• Redundancy + hot swap: maximizes uptime for continuous chemical processes
• Corrosion‑resistant & wide‑range temp: long service life in harsh chemical environments
• High precision & EMC compliance: stable control, less quality variation
• Seamless ABB ecosystem fit: easy upgrade and integration with existing systems

---

Short Version (for Catalog / Bidding)

ABB 3BHE023784R2530 (PPD113B01-25-111000) is a redundant power supply + combi I/O controller for ABB AC 800PEC and Symphony Plus DCS/PLC systems. With 25 W 24 VDC redundant power, hot swap, 16‑bit precision I/O, and conformal coating, it is ideal for chemical, petrochemical, and hazardous‑area applications, ensuring high reliability and 24/7 operation.
