ABB PFCL201C 10KN High Precision Tensiometer & Load Cell

Product Overview

The ABB PFCL201C 10KN is a high-performance PillowBlock type tension and load cell from ABB Pressductor® series, with a rated capacity of 10 kN. Adopting proprietary magnetoelastic measurement technology, it delivers contact-free, wear-free and highly stable force detection. Engineered for tension control and vertical force measurement, this unit is widely applied in papermaking, metallurgy, lithium battery production and other harsh industrial environments.

Key Features

• High Precision Measurement Overall accuracy: ±0.25% FS, repeatability: ±0.1% FS, resolution up to 0.01% FS, ensuring reliable closed-loop control performance.
• Robust Construction Made of integrated high-strength stainless steel with full potting internal structure. Resists impact, vibration, dust and corrosion. Vertical ultimate overload: 100 kN, lateral ultimate overload: 25 kN.
• Wide Temperature Adaptability Operating temperature range: -40°C ~ +80°C. Built-in temperature compensation effectively minimizes signal drift under extreme temperatures.
• Excellent Protection Class IP67 rated, fully dust-tight and temporary immersion resistant, suitable for wet, dusty and corrosive working conditions.
• Easy Installation & Integration Standard PillowBlock design for simple bolt/flange mounting. Equipped with circular connector. Available with 2mV/V, 4-20mA or 0-10V analog output; optional RS485, Modbus RTU and Profibus DP communication interfaces.
