ABB PFCL201C10KN 10KN Tension Monitoring Module ABB Original_Xiamen XingRuiJia Import and Export CO,LTD

Model：ABB PFCL201C10KN 10KN Tension Monitoring Module ABB Original

Brand: ABB
Price range (USD): ¥6,500 – ¥7,200
Country: Australia|Angola|Bulgaria|Brazil|China|Chile|Canada|England|Finland|Germany|Greece|HongKong|Hasakesitan|Iran|Italy|India|Indonesia|Japan|Korea|Myanmar|Morocco|Monglia|Norway|Portugal|Peru|Pakistan|Russia|Srilanka|Singapore|Spain|South-Africa|Tunisia|Turke
Parameter: Parameter Specification
Model PFCL201C10KN
Manufacturer ABB (Original)
Rated Capacity 10 kN
Order Number 3BSE027070R10
Accuracy ±0.25% FS
Repeatability ±0.1% FS
Resolution 0.01% FS
Standard Output 2 mV/V
Optional Output 4–20 mA / 0–10 V
Overload (Allowable) 15 kN
Overload (Vertical Ultimate) 100 kN
Overload (Lateral Ultimate) 25 kN
Housing Material Stainless Steel
Protection Class IP67
Operating Temperature ‑40°C ~ +80°C

ABB PFCL201C10KN 10KN Tension Monitoring Module – ABB Original

Product Overview

The ABB PFCL201C10KN (Order No.: 3BSE027070R10) is an original ABB high‑performance tension monitoring module with a rated capacity of 10 kN. Built on ABB’s proven Pressductor® magnetoelastic technology, it delivers contact‑free, wear‑free force and tension measurement for demanding industrial environments. As a genuine ABB component, it ensures original quality, full compatibility, and reliable after‑sales support, making it the ideal choice for critical tension control applications.

Key Features
Genuine ABB Original Quality Manufactured strictly to ABB’s global standards, with complete traceability and original factory warranty. Perfectly compatible with ABB PLC/DCS systems for seamless integration and stable long‑term operation.
Precision Tension Monitoring Rated load: 10 kN; Overall accuracy: ±0.25% FS; Repeatability: ±0.1% FS; Resolution: 0.01% FS. Delivers accurate, real‑time tension data for closed‑loop control.
Robust Stainless Steel Construction One‑piece stainless steel housing with fully encapsulated internals. Resists corrosion, impact, vibration, dust, and moisture—ideal for harsh industrial settings.
High Overload Resistance Allowable overload: 15 kN (150% FS); Ultimate vertical overload: 100 kN; Ultimate lateral overload: 25 kN. Protects against sudden load spikes.
IP67 Protection & Wide Temperature Range IP67 rated (dust‑tight, temporary water immersion resistant). Operating temperature: ‑40°C to +80°C, with built‑in temperature compensation for minimal signal drift.
Flexible Output & Easy Installation Standard 2 mV/V output; optional 4–20 mA / 0–10 V analog signals. Pillow‑block design for simple bolt mounting. Supports RS485, Modbus RTU, Profibus DP for easy system integration.

Technical Specifications

表格

Parameter	Specification
Model	PFCL201C10KN
Manufacturer	ABB (Original)
Rated Capacity	10 kN
Order Number	3BSE027070R10
Accuracy	±0.25% FS
Repeatability	±0.1% FS
Resolution	0.01% FS
Standard Output	2 mV/V
Optional Output	4–20 mA / 0–10 V
Overload (Allowable)	15 kN
Overload (Vertical Ultimate)	100 kN
Overload (Lateral Ultimate)	25 kN
Housing Material	Stainless Steel
Protection Class	IP67
Operating Temperature	‑40°C ~ +80°C

Applications

Steel Mills: Tension monitoring of metal strips during rolling, galvanizing, and pickling.
Paper Mills: Web tension control in papermaking, coating, and calendering lines.
Converting Industries: Film, foil, textile, and wire production.
General Industry: Any process requiring reliable, high‑precision tension/force measurement.
