ABB PM866AK01 (3BSE076939R1) Redundant CPU for Critical Processes

Product Overview

ABB PM866AK01, part number 3BSE076939R1, is a professional redundant CPU module designed for critical industrial processes. As the core controller of ABB AC800M and System 800xA platforms, it features built-in full redundancy architecture. It delivers reliable real-time control, excellent anti-interference capability and uninterrupted operation, perfectly suited for facilities where system downtime is strictly prohibited. This original ABB module is widely used in power, chemical, metallurgy and other high-demand industrial fields.

Key Features

1. Full Redundancy for Maximum Operational Reliability

Supports complete redundancy of CPU, CEX bus, network and S800 I/O modules. The switchover time is less than 10 ms, realizing seamless hot swap and failover. It thoroughly avoids production halt and economic loss caused by single-point failure, fully meeting the safety requirements of critical production processes.

2. Stable High-performance Processing

Equipped with industrial PowerPC processor, it executes control logic rapidly and stably. It supports multi-task operation and complex control algorithms, ensuring fast response and high-precision regulation for continuous production lines. Large-capacity memory guarantees smooth running of large-scale application programs and data storage.

3. Rich Communication Interfaces

Dual Ethernet ports are configured for redundant network transmission, ensuring stable data communication. Two RS-232C serial ports are available for local configuration, debugging and remote connection. It is compatible with mainstream industrial protocols, enabling easy connection with upper monitoring systems and third-party automation equipment.

4. Industrial-grade Environmental Adaptability

IP20 protection rating, suitable for standard industrial control cabinets. It works steadily within 0°C ~ 60°C, and withstands vibration, impact and strong electromagnetic interference on site. Certified by CE, UL and IEC standards, it adapts to various harsh industrial working conditions.

5. Easy Installation & System Compatibility

Adopts standard DIN rail mounting for quick installation, replacement and maintenance. Fully compatible with ABB System 800xA and AC800M series systems, supporting one-stop configuration, program download and fault diagnosis via dedicated engineering software.

Technical Specifications

表格

Item	Parameter
Model	PM866AK01
Part Number	3BSE076939R1
Type	Redundant Process CPU
Processor	Industrial PowerPC
Redundancy Mode	CPU / Bus / Network / I/O Redundancy
Switchover Time	≤ 10 ms
Ethernet	2 × RJ45 (Redundant)
Serial Port	2 × RS-232C
Power Supply	24 V DC
Protection Class	IP20
Operating Temperature	0°C ~ +60°C
Humidity	5% ~ 95% (Non-condensing)
Compatible System	ABB AC800M, System 800xA
Certifications	CE, UL, IEC 61131-2

Main Applications

• Power industry: Thermal power, hydropower and combined cycle power plant control systems
• Chemical & petrochemical: Continuous production lines with high safety requirements
• Metallurgy: Steel rolling, galvanizing and pickling production lines
• Pulp & paper: Full-process control of papermaking equipment
• Water treatment: Municipal and industrial wastewater treatment systems

Product Strength

This redundant CPU is specially optimized for critical processes requiring 24/7 uninterrupted operation. With comprehensive redundancy design, strong processing performance and outstanding stability, it effectively improves system safety and availability. It is the preferred core control component for new construction, renovation and redundancy upgrade of high-reliability DCS and PLC systems.
