1. Overview

The ABB 5SHX1960L0004 is a high-performance industrial IGBT power semiconductor module, serving as the core power switching device of ABB medium voltage drive and medium voltage frequency converter systems. It undertakes high-power AC-DC and DC-AC energy conversion tasks inside medium voltage converters, controlling the on-off of large current to realize speed regulation and torque control of medium voltage heavy-duty motors.

This IGBT semiconductor module is widely applied in mining hoist medium voltage drives, metallurgical rolling mill medium voltage converters, power plant large fan and water pump drive equipment, as well as port heavy lifting motor control systems. Its stable high-current bearing performance ensures the continuous heavy-load operation of large medium voltage drive equipment.

Adopting ABB self-developed advanced semiconductor chip technology, the 5SHX1960L0004 IGBT features low switching loss, strong overload resistance and built-in multi-layer heat dissipation structure. It is the standard original replacement spare part for medium voltage drive equipment breakdown maintenance and cabinet overhaul in all heavy industrial fields.

2. Product Features

Low Loss High Power Semiconductor Chip

Adopts advanced IGBT chip design with tiny switching power loss, effectively reducing heat generation during long-term heavy-load operation of medium voltage drives and lowering cabinet heat dissipation pressure.

Strong Overload & High Current Bearing Capacity

Supports instantaneous large current overload impact, stable output under full-load continuous working conditions, perfectly matches the power demand of large medium voltage industrial motors.

Integrated Multi-Layer Safety Protection

Built-in temperature sensing and current detection circuits, automatically block power switching under overheating and overcurrent faults to avoid permanent burnout of medium voltage drive main circuits.

Optimized Heat Conduction Structure

Integrated high-efficiency heat conduction substrate, fits well with drive cabinet cooling system, maintains stable chip working temperature even under 24-hour continuous heavy-load production.

Perfect Matching ABB Medium Voltage Drive Equipment

Native hardware matching with ABB medium voltage converter power units, consistent with factory original module parameters, no performance attenuation after replacement, no debugging required for on-site installation.

3. Structure and Composition

The ABB 5SHX1960L0004 IGBT power semiconductor module adopts an integrated sealed power packaging structure, composed of high-power IGBT semiconductor core chip, built-in temperature detection sensor, high-current conductive terminals, heat conduction substrate and industrial insulated sealing shell.

In medium voltage drive equipment, the IGBT chip controls the on-off of high-power current to complete frequency conversion and voltage regulation of medium voltage power supply, driving large industrial medium voltage motors to run at variable speeds. The built-in temperature sensor monitors chip temperature in real time and triggers protection action when overheating occurs. The sealed insulation shell isolates high-voltage current to prevent electric leakage and short-circuit risks inside the medium voltage cabinet.

4. Application Fields

Mining Medium Voltage Hoist & Conveyor Drive

Core power semiconductor replacement part for underground mine medium voltage hoist and large belt conveyor frequency converter equipment.

Metallurgical Rolling Mill Medium Voltage Converter

Key IGBT module for high-power medium voltage drive cabinets of steel rolling and heating furnace large motors.

Thermal Power Plant Auxiliary Medium Voltage Equipment

Spare power component for power plant large fan, circulating water pump medium voltage variable frequency drive control system.

Port Heavy Lifting & Container Handling Machinery

High-power IGBT spare part for port gantry crane and container lifting medium voltage motor drive equipment.

Cement & Building Material Heavy Production Line

Medium voltage converter core power module for cement kiln, large grinding mill high-power drive cabinet maintenance.

----------------------------------------------------------------
