ABB 5SHX14H4502 / 5SXE05-0152 IGCT Module | 3BHB003230R0101 & 3BHB003023P201

Product Overview

ABB 5SHX14H4502 (Part No: 3BHB003230R0101) and ABB 5SXE05-0152 (Part No: 3BHB003023P201) belong to ABB classic 5SHX & 5SXE series asymmetric IGCT (Integrated Gate Commutated Thyristor) press-pack power modules. These units are widely used as original spare power switching components for ABB medium voltage converter stacks and ACS6000 variable frequency drive systems.

5SHX14H4502 integrates thyristor wafer together with gate commutated structure, while 5SXE05-0152 is the matched IGCT power device for MV converter cabinets. Both press-pack modules feature low conduction loss, high surge current capability and fiber-optic gate triggering. Designed for 24/7 continuous heavy-duty operation, they are commonly replaced parts for maintenance, overhaul and retrofit of aging medium voltage power conversion equipment.

Key Features of ABB 5SHX14H4502 & 5SXE05-0152

• Press-pack capsule packaging, compatible with liquid water cooling or forced air cooling stack assembly
• Fiber optic gate signal interface, excellent electrical isolation and strong anti-interference performance
• Asymmetric IGCT structure, optimized for high-efficiency unidirectional power conversion
• Low on-state voltage drop to reduce heat generation and system power consumption
• High overload & surge current tolerance to handle transient load spikes
• Snubberless operation supported in many standard ABB converter topologies
• Long service lifetime, high MTBF for continuous industrial heavy-load operation
• Full original matching for ABB ACS6000 medium voltage drive power stacks
• IEC & CE certified, suitable for harsh cabinet industrial environments

Technical Specifications

Core Application Scenarios

These two ABB IGCT modules are paired together in medium voltage high-power converter stacks for multiple heavy-duty sectors:

1. ABB ACS6000 Medium Voltage Variable Frequency Drives

The most typical application for 5SHX14H4502 and 5SXE05-0152. Used for large motor speed control: mining hoists, cement rotary kilns, metallurgical rolling mills, large water pumps and industrial fans. They control high-power motor torque and realize energy-saving speed regulation.

2. STATCOM & SVC Grid Reactive Power Compensation

Installed inside static synchronous compensator and FACTS grid stabilization systems. The IGCT stacks regulate reactive power, stabilize grid voltage, suppress voltage flicker and improve power quality for steel mills, chemical plants and large industrial power networks.

3. New Energy Power Conversion

Used in wind farm grid-connected converters and large-scale PV inverter systems. Convert DC power from renewable sources to AC grid power, achieve grid synchronization and stable power output. Also used in early generation grid-side energy storage converters.

4. Oil & Gas Industry Medium Voltage Converters

For offshore platform power supply, high-power gas compressors and long-distance pipeline pump drives. The robust press-pack structure withstands vibration and temperature fluctuation in remote oilfield cabinet environments.

5. Marine & Heavy Industry Special Power Supplies

Medium voltage power conversion equipment for ship auxiliary power systems and heavy industrial emergency power supplies. Suitable for continuous operation requirements of critical infrastructure.

Why Buy ABB 5SHX14H4502 / 5SXE05-0152 From Us

We supply original tested ABB IGCT spare parts: 5SHX14H4502 (3BHB003230R0101) and 5SXE05-0152 (3BHB003023P201). Ideal for converter maintenance, replacement and system upgrade projects.

• Original tested stock available
• Functional test report can be supplied before shipment
• Technical support for IGCT stack replacement, clamping force setup and commissioning
• Worldwide export shipping to Asia, Europe, Middle East, South America, Africa
• Competitive bulk pricing for large spare parts orders

Frequently Asked Questions

What is 5SHX14H4502 3BHB003230R0101?

ABB 5SHX14H4502 with part code 3BHB003230R0101 is an asymmetric press-pack IGCT power module, a standard power device for ABB ACS6000 medium voltage converter stacks.

What is 5SXE05-0152 3BHB003023P201?

ABB 5SXE05-0152 (3BHB003023P201) is an asymmetric IGCT module used in ABB medium voltage drives, often used together with 5SHX14H4502 inside the same power stack.

Can I replace 5SHX14H4502 directly with other IGCT models?

Direct cross replacement is not recommended. You must verify voltage rating, stack topology, clamping force, fiber gate drive parameters and cooling system before substitution.

What should be noted when installing these press-pack IGCT modules?

Press-pack IGCT requires specified clamping force during assembly. Proper torque control, surface cleaning and high-voltage discharge safety procedures are mandatory before installation and commissioning.
