ABB PFCL201C 10KN

Product Overview

The ABB PFCL201C 10KN belongs to ABB Pressductor PillowBlock load cell family, designed for vertical force component measurement in strip/web tension control systems. Adopting Pressductor magnetoelastic measurement principle, it realizes non-contact force detection without mechanical wear, maintaining stable precision under long-cycle industrial operation.

Machined from a single stainless steel block, PFCL201C 10KN features outstanding overload, shock and impact resistance. The encapsulated internal electronics deliver strong dustproof and anti-corrosion performance with IP67 protection grade, suitable for harsh mill environments such as galvanizing lines and pickling lines. This 10kN PillowBlock sensor works together with ABB PFEA111 / PFEA112 tension amplifiers to send tension signal to PLC and DCS systems for closed-loop web tension control.

Key Features

1. Rated capacity: 10 kN (2250 lbs), extended load up to 15kN, high overload capacity in measurement direction
2. Pressductor magnetoelastic technology, no moving parts, low maintenance
3. One-piece stainless steel construction, vibration & shock resistant
4. Protection class IP67, reliable in dusty, humid and corrosive workshop
5. Wide measuring range ratio up to 30:1, adaptable to varied web materials
6. Cannon connector design (PFCL201C standard version), simple bolt-on mounting
7. High repeatability and stable output for continuous web processing
8. Mill-duty optional version available for heavy-duty metallurgy production lines

Technical Specifications

Application Fields

ABB PFCL201C 10KN PillowBlock load cell is widely applied in industries requiring continuous web tension monitoring: ✅ Metallurgy: Steel strip rolling, coating line, galvanizing line, pickling line tension control ✅ Paper & Printing: Paper web tension measurement to avoid paper break ✅ Plastic & Film: BOPP, PET film slitting & winding tension control ✅ Textile & Nonwoven: Fabric and nonwoven web tension monitoring ✅ Converting machinery, packaging slitter, web processing equipment

Matching Accessories

• ABB PFEA111 / PFEA112 Tension Controller / Amplifier
• Matching signal cable for Pressductor load cell
• Installation mounting brackets

Our Service

We supply original ABB PFCL201C 10KN PillowBlock load cell, full range ABB Pressductor tension sensors (PFCL201 / PFTL201 series). ✔ In stock, fast delivery ✔ Original genuine product inspection ✔ Technical support for installation, wiring and system commissioning ✔ Complete datasheet and manual available upon request

Contact us for quotation, specification sheet and stock availability of ABB PFCL201C 10KN.
