ABB LT2005-S/SP19
Product Overview
The ABB LT2005-S/SP19, part number 3BHB014827R0001, is a high-performance closed-loop Hall effect current transducer for precise AC and DC current measurement in high-power industrial systems. This sensor adopts compensated Hall principle to achieve galvanic isolation between primary high-current side and secondary signal circuit, protecting control system from high voltage interference.
With rated primary current up to 2000Arms and transformation ratio of 1:4000, LT2005-S/SP19 delivers excellent linearity, low temperature drift and high immunity against external magnetic fields. Panel mounting design simplifies installation inside power cabinets, widely deployed in ABB power converters, medium voltage drives and renewable energy power conversion equipment. It is a genuine spare component for ABB industrial power systems.
Key Features
- Part Number: 3BHB014827R0001, Model: LT2005-S/SP19
- Closed-loop Hall effect technology, high accuracy & great linearity
- Rated primary current: 2000 Arms
- Conversion ratio: 1 / 4000
- Full galvanic isolation between primary and secondary circuits
- Wide operating temperature: -25 ℃ ~ +70 ℃
- Panel mount structure, easy cabinet integration
- Low temperature drift, strong anti-magnetic interference capability
- Compact robust housing, reliable continuous operation
- Suitable for AC, DC and pulse current measurement
Technical Specifications
| Item |
Specification |
| Model |
LT2005-S/SP19 |
| ABB Part No. |
3BHB014827R0001 |
| Type |
Closed-loop Hall Effect Current Transducer |
| Rated Primary Current |
2000 Arms |
| Transformation Ratio |
1 : 4000 |
| Measurement Signal |
AC / DC / Pulse Current |
| Isolation |
Galvanic isolation between primary & secondary |
| Mounting |
Panel Mount |
| Operating Temperature |
-25℃ ~ +70℃ |
| Net Weight |
1.687 kg |
| Origin |
Finland |
| HS Code |
85043129 |
Application Fields
ABB LT2005-S/SP19 current transducer is used for high-power current monitoring in: ✅ Industrial medium & high voltage frequency converters ✅ Power inverter and rectifier units ✅ Renewable energy converter (solar, wind power) ✅ Railway traction power equipment ✅ Heavy-duty motor drive systems ✅ Energy storage power cabinet ✅ Industrial power quality monitoring
Matching Accessories
- Signal connecting wire for Hall current transducer
- Installation mounting hardware
- Drive control board and signal processing module
Our Service
We supply original ABB LT2005-S/SP19 (3BHB014827R0001) current transducer and full series ABB drive spare parts. ✔ Ready stock & fast delivery ✔ Original product inspection ✔ Datasheet, wiring diagram and installation guide available ✔ Professional technical support for replacement, commissioning and troubleshooting ✔ Bulk order discount for system integrators
Contact us to get quotation, stock status and full datasheet of ABB LT2005-S/SP19.
