ABB TVOC-2-240 1SFA664001R1001
Product Overview
The ABB TVOC-2-240, order code 1SFA664001R1001, is the main controller unit of ABB Arc Guard System™, a high-speed arc flash protection monitor designed for low voltage and medium voltage switchgear cabinets. It detects arc flash via optical fiber sensors. Once arc light is captured, the unit outputs trip signal to circuit breaker within 1 ms, rapidly cutting power to minimize explosion energy, protect field operators and electrical equipment, and reduce production downtime. TVOC-2-240 is SIL 2 functional safety certified, equipped with HMI panel and door mounting accessories. It supports expansion modules to increase optical detector channels, widely adopted in power distribution and industrial power cabinet safety retrofit projects.
Key Features
- Part Number: 1SFA664001R1001, Model: TVOC-2-240 Arc Monitor
- SIL 2 functional safety certification for arc flash protection
- Ultra-fast response: trip signal output within 1 millisecond
- 10 built-in optical detector inputs; expandable up to 30 sensors with extension units
- Supports zone selective tripping, can trigger up to 3 circuit breakers
- Power supply: 100–240 V AC / DC, 50/60Hz
- Integrated HMI, configurable parameters, event log and fault recording
- Modbus RTU communication for SCADA / DCS system connection
- DIN rail or wall mounting, flexible cabinet installation
- Pre-calibrated optical sensors, no on-site calibration required, simple commissioning
Technical Specifications
| Item |
Specification |
| Model |
TVOC-2-240 |
| ABB Order Code |
1SFA664001R1001 |
| Product Type |
Arc Monitor / Arc Flash Protection Relay |
| System |
ABB Arc Guard System™ |
| Safety Level |
SIL 2 |
| Detector Input |
10 optical sensor inputs (expandable to 30) |
| Response Time |
≤1 ms trip signal output |
| Power Supply |
100–240 V AC / DC, 50/60Hz |
| Communication |
Modbus RTU |
| Mounting |
DIN rail / Wall mount |
| HMI |
Included, door mount accessories supplied |
| Application |
LV & MV switchgear arc fault protection |
| Certificate |
CE, SIL2 |
Application Fields
ABB TVOC-2-240 1SFA664001R1001 arc monitor is widely used for arc flash safety protection: ✅ Medium & low voltage switchgear cabinets ✅ Data center power distribution panels ✅ Oil & gas, petrochemical power rooms ✅ Mining heavy industry power system ✅ Marine power distribution equipment ✅ Hospital, commercial building main power cabinet ✅ Steel mill, paper plant industrial distribution boards ✅ Power plant auxiliary switchgear
Matching Accessories
- Optical fiber arc detectors (different lengths)
- TVOC-2 extension units
- CSU-2 current sensing unit (light + current dual verification)
- Mounting brackets, HMI door mount kit
- Communication cables, fiber holders
Our Service
We supply original ABB TVOC-2-240 (1SFA664001R1001) arc monitor and full range ABB Arc Guard System spare parts. ✔ Ready stock & fast international shipment ✔ Original genuine inspection ✔ Datasheet, wiring diagram and commissioning guide available ✔ Technical support for cabinet retrofit, programming and troubleshooting ✔ Bulk quotation for system integrators & EPC contractors
Contact us to get quotation, stock status and full datasheet of ABB TVOC-2-240 1SFA664001R1001.
