1. Product Overview

ABB LXN1604-6, material code 3BHL000986P7000, belongs to ABB Convert Select series high-power DIN rail switching power supply, the dedicated power backbone of ABB Ability™ System 800xA DCS, Industry 4.0 smart factory and digital process automation architecture. Rated 500W / 24.7VDC 20A output with native dual redundant input, it supplies continuous clean power to:

• AC800M CPU controllers, S800 I/O stations
• NE800 series industrial Ethernet communication switches
• HMI operator panels, field smart transmitters, safety relay modules
• Medium voltage drive control boards, UNITROL generator excitation units Its redundant power design eliminates single-point power blackout risk for smart factory digital communication networks and core control loops, guaranteeing 24/7 stable data transmission, edge computing and cloud data upload for Industry 4.0 intelligent production lines. We supply 100% brand-new original ABB units with full spot inventory, fast global door-to-door delivery and standard 12-month manufacturer warranty.

2. Core Technical Specifications

表格

Parameter Item	Standard Specification
Full Part Number	LXN1604-6 / 3BHL000986P7000
Rated DC Output	24.7VDC (24V industrial standard), 20A, total power 500W
Dual Redundant Input	Dual independent channels: AC 85–264V universal mains / DC 90–350VDC UPS battery backup
Energy Efficiency	Up to 93% peak full-load efficiency, low heat loss for cabinet intelligent equipment
Wide Operating Temperature	-20℃ ~ +70℃ continuous stable operation (derating above 55℃)
Storage Temperature	-40℃ ~ +85℃
Mounting	Standard 35mm DIN rail snap-on metal finned heat dissipation housing, IP20 cabinet internal use
Redundancy Mechanism	Built-in decoupling diodes, microsecond seamless input switchover, no external redundant module required
Parallel Expansion	Multiple modules paralleled to build N+1 redundant power architecture for large multi-cabinet smart factory systems
Complete Protection Suite	OVP overvoltage, OCP overcurrent, hiccup short-circuit auto-recovery, over-temperature thermal shutdown, input undervoltage lockout, multi-stage EMC surge filtering
Status Indicator	Power OK green LED + dual input channel fault alarm light for smart cabinet remote monitoring
Dimension & Weight	194 × 113.6 × 138 mm, approx. 2.8kg
Certifications	CE, UL, IEC61010 industrial safety & EMC standards, compatible with ABB Ability digital system certification

3. Core Value for ABB Ability 800xA Industry 4.0 Smart Factory

3.1 Power Guarantee for Full Digital Communication Network (Match NE800 Series Switches)

All 800xA industrial Ethernet communication switches (NE801/NE810/NE820) rely on LXN1604-6 for stable 24V power supply. Ultra-low ripple DC output avoids network packet loss, switch offline and Industry 4.0 big data transmission interruption caused by power surge or voltage fluctuation. Dual redundant input ensures communication network zero downtime during mains power switching, supporting real-time production data collection, MES interconnection and cloud platform remote monitoring for smart factories.

3.2 Native Matching ABB Ability 800xA Full Automation Hardware Ecosystem

Optimized output parameters perfectly compatible with the entire 800xA hardware stack: AC800M controllers, S800 smart I/O, CI series communication interfaces, PP825 HMI, RB520 safety relays and intelligent field sensors. Unified power architecture simplifies Industry 4.0 cabinet standardized design, fully compatible with Control Builder M engineering software and ABB Ability digital twin platform configuration.

3.3 Dual Redundant Input Eliminates Single-Point Failure of Smart Production Lines

Two isolated independent input terminals support dual mains + UPS battery redundant power supply. When one power source fails, the module completes seamless switchover within microseconds without DCS system reset or communication network disconnection. Critical for intelligent chemical, metallurgy and cement Industry 4.0 workshops, preventing production line stop, digital data loss and safety interlock failure. Built-in decoupling circuit reduces extra wiring cost for smart cabinet layout.

3.4 High Efficiency + Wide Temperature Adaptability for Digital Intelligent Control Rooms

93% ultra-high conversion efficiency drastically cuts heat accumulation inside dense intelligent cabinets loaded with switches, controllers and edge computing modules, extending service life of all digital communication and control hardware. Ultra-wide -20℃ ~ +70℃ operating range stably operates in cold northern smart equipment rooms, high-temperature boiler digital control cabinets and poorly ventilated metallurgical intelligent converter rooms without auxiliary cooling fans, meeting harsh site requirements of Industry 4.0 unmanned factories.

3.5 Multi-Layer Hardware Protection Safeguards High-Value Digital Automation Equipment

• Input undervoltage lockout: Prevent unstable low voltage from crashing Ethernet switches and 800xA controllers
• Hiccup short-circuit protection: Auto recover after field wiring short fault removal without permanent burnout of communication modules
• Over-temperature thermal shutdown: Avoid power supply failure under overloaded intelligent cabinet heat accumulation
• Multi-stage EMC filter: Suppress harmonic interference from medium voltage drives, eliminate communication network mis-triggering and signal disconnection in high-noise smart workshops

3.6 Modular DIN Rail Design Supports Flexible Industry 4.0 System Expansion & Maintenance

Quick plug-in wiring terminals enable single-unit replacement without full cabinet power cut, minimizing smart factory production downtime during equipment maintenance. Multiple LXN1604-6 modules can be freely paralleled to expand power capacity for large-scale distributed ABB Ability 800xA multi-cabinet intelligent production lines, flexible for factory digital transformation and Industry 4.0 capacity expansion projects.

3.7 Industrial-Grade Long-Life Components for 24/7 Unmanned Smart Factory Operation

All internal power transformers, switching tubes and long-life electrolytic capacitors adopt ABB industrial-grade standards; conformal coated internal circuit boards resist dust, moisture and weak corrosive gas in chemical, cement and metallurgical intelligent workshops. Each unit passes factory full-load aging, vibration and damp-heat cycle testing before delivery, ultra-low long-term failure rate compared with generic imitation power supplies, reducing Industry 4.0 system operation and maintenance labor cost.

4. Main Industry 4.0 Smart Factory Application Scenarios

1. Thermal & Hydropower Digital Power Plants: ABB Ability 800xA boiler/turbine intelligent control cabinet redundant power supply, supporting NE800 communication switches and UNITROL excitation digital network
2. Chemical & Petrochemical Intelligent Factories: SIS safety digital interlock system, reactor intelligent monitoring central cabinet uninterrupted power core for Industry 4.0 digital twin platform
3. Metallurgy Smart Rolling Mills: PCS6000 medium voltage drive matching 800xA intelligent auxiliary cabinet power supply, guaranteeing production line real-time data transmission via industrial Ethernet switches
4. Cement & New Energy Intelligent Production Lines: Rotary kiln Industry 4.0 main drive, wind power full-power converter digital control cabinet stable power source for communication network equipment
5. Water Treatment Environmental Intelligent Plants: Sewage pump group centralized S800 smart I/O station and Ethernet switch dedicated redundant power supply

5. Original In-Stock & Global Fast Shipping Service

All ABB LXN1604-6 / 3BHL000986P7000 industrial power supply modules we provide are 100% genuine original factory products, complete with sealed original packaging, official factory full-performance test reports, covered by a formal 12-month warranty against manufacturing defects under rated operating conditions. Our warehouse holds abundant permanent ready stock to rapidly process urgent smart factory digital cabinet maintenance orders and bulk procurement for global Industry 4.0 EPC automation projects. We adopt professional anti-static, shockproof and moisture-proof dedicated export packaging to protect internal power circuit components during long-distance sea and air international transportation. We cooperate with DHL/Fedex/UPS for fast worldwide delivery covering Europe, North America, Southeast Asia, the Middle East and all major process industrial regions, with one-stop customs clearance support.
Our supporting services include pre-sales ABB Ability 800xA cabinet power load calculation, redundant power system topology design, dual input wiring scheme consultation, plus after-sales DIN rail installation, redundancy function debugging, Ethernet switch power matching and complete Industry 4.0 DCS digital automation system overall commissioning.

Product Value Summary

Selecting genuine original ABB LXN1604-6 redundant power module delivers zero-interruption stable 24V high-power supply for NE800 communication switches, AC800M controllers and all digital hardware in ABB Ability 800xA Industry 4.0 smart factory systems. Original ABB power electronic quality eliminates single-point power outage, network communication collapse and expensive digital module burnout risks from counterfeit power supplies, effectively cutting unplanned intelligent production line shutdown frequency and long-term Industry 4.0 operation maintenance costs. Supported by ample spot inventory, efficient global fast shipping and complete 12-month warranty protection, it is the indispensable redundant power backbone spare component for full-process ABB digital smart factory automation projects.
