ABB LXN1604-6 (3BHL000986P7000) Redundant DIN Rail Power Supply

Reliable Power Backbone for ABB 800xA Controller Pairing & Synchronization Industrial Network 100% Original ABB Genuine Component, Full Spot In Stock, Fast Global Door-to-Door Shipping

1. Product Overview

ABB LXN1604-6, material code 3BHL000986P7000, belongs to ABB Convert Select high-power switching power supply, customized for ABB Ability™ System 800xA DCS redundant control network architecture.

Core Role for 800xA Controller Pairing & Synchronization Network

All core network devices that realize redundant controller hot standby pairing, clock synchronization and RNRP redundant network transmission rely on this power supply for continuous clean DC power supply, including:

1. NE800 series managed industrial Ethernet switches (core equipment for controller data synchronization);
2. Dual redundant AC800M PM series controllers, CEX-bus BC810 interconnection baseplates;
3. TC811 fiber Ethernet adapters, CI series communication interface modules;
4. HMI operator panels, S800 I/O station network modules and safety interlock units. Its native dual redundant input design eliminates single-point power failure risk of the control network, avoids controller synchronization interruption, redundant pairing breakdown and real-time production data loss caused by power fluctuation or power cut, and ensures deterministic stable operation of the 800xA redundant control network. We supply brand-new original ABB power supplies with complete factory calibration test reports, abundant permanent spot inventory, expedited global logistics and standard 12-month manufacturer original warranty.

2. Core Technical Specifications (Network Synchronization Scenario Targeted)

表格

Parameter Item	Standard Specification
Full Part Number	LXN1604-6 / 3BHL000986P7000
Rated DC Output	24.7VDC (24V industrial standard), 20A, total power 500W
Dual Redundant Input	Dual isolated independent channels: AC 85–264V universal factory mains / DC 90–350VDC UPS battery backup
Conversion Efficiency	Up to 93% peak full-load efficiency, low heat accumulation for densely arranged switch & controller cabinets
Operating Temperature Range	-20℃ ~ +70℃ continuous stable operation (derating required above 55℃)
Humidity & Corrosion Resistance	5%–95% RH non-condensing, full PCB polyurethane conformal coating anti-moisture, salt mist and corrosive gas
Mechanical Shock & Vibration	Comply with IEC 60068-2-6 industrial vibration standard, adapt to long-term vibration of factory control rooms
Mounting Form	Standard 35mm DIN rail snap-on metal finned heat sink housing, IP20 cabinet internal protection
Redundancy Switch Mechanism	Built-in isolation decoupling diodes, microsecond seamless switching between two input power sources, no external redundant module required
Parallel Expansion Capacity	Multiple modules can be paralleled freely to build N+1 redundant power architecture for multi-cabinet large-scale 800xA network systems
Complete Multi-Layer Protection Suite	OVP overvoltage, OCP overcurrent, hiccup short-circuit auto-recovery, over-temperature thermal shutdown, input undervoltage lockout, multi-stage EMC surge filtering
Status Indicator	Power OK green LED + dual input channel independent fault alarm light, support remote cabinet network operation monitoring
Dimension & Net Weight	194 × 113.6 × 138 mm, approx. 2.8kg
Certifications	CE, UL, IEC61010 industrial safety & EMC standards, fully compatible with ABB 800xA RNRP redundant synchronization network protocol

3. Key Advantages for 800xA Controller Pairing & Synchronization Network

3.1 Ultra-Low Ripple Clean DC Power Avoids Network Synchronization Signal Distortion

Optimized soft-switching power conversion circuit outputs ultra-low noise and low-ripple 24V DC power, completely suppress voltage surge, transient ripple and high-frequency interference that easily trigger NE800 switch port packet loss, controller clock synchronization offset and redundant pairing disconnection. Guarantee microsecond-level deterministic real-time data interaction between primary and standby AC800M controllers, eliminate synchronization delay and control logic disorder of the redundant network.

3.2 Dual Redundant Input Zero Interruption Protect Redundant Controller Pairing Network

Two fully isolated independent input terminals support dual mains + UPS battery dual backup power supply. When one power source fails, voltage drops or surges, the module completes seamless power switching within microseconds without power cut-off of Ethernet switches and dual controllers. Avoid catastrophic faults such as controller synchronization collapse, hot standby pairing failure and whole plant control system offline caused by single power supply breakdown, which is the core guarantee for the safety of 800xA redundant control network.

3.3 Full Conformal Coating Anti-Harsh Environment Design Stable Long-Term Network Operation

The entire internal circuit board is covered with industrial anti-corrosion conformal coating, forming an airtight protective layer to isolate damp steam, salt mist, oil mist and weak acid/alkali gas in chemical, metallurgy, hydropower and coastal factories. Prevent PCB pin oxidation, leakage current drift and intermittent power supply faults, effectively solve the problem of periodic synchronization failure of controller network caused by humid and corrosive cabinet environments.

3.4 93% High Efficiency Reduce Cabinet Heat Load for Dense Network Cabinets

800xA redundant control cabinets are densely equipped with multiple NE800 switches, dual controllers and communication modules, and heat accumulation easily triggers equipment over-temperature protection and network communication jitter. The ultra-high-efficiency topology greatly reduces power loss and heat generation, lowers internal cabinet temperature difference to avoid condensation on network module circuit boards, extends the service life of core synchronization network hardware, and reduces long-term factory energy consumption cost.

3.5 Multi-Stage EMC Filter Resists Industrial Interference Stabilize RNRP Synchronization Network

Integrated multi-level LC surge filtering and shielding circuit, effectively suppress high-frequency harmonic interference generated by medium voltage inverters, welding equipment and large motors in industrial workshops. Avoid RNRP redundant network protocol parsing errors, controller clock deviation and redundant pairing failure caused by electromagnetic noise, ensure consistent synchronization timestamp of primary and standby controllers.

3.6 Complete Hardware Protection Prevent Expensive Network & Controller Equipment Burnout

• Input undervoltage lockout: Prevent unstable low voltage from crashing NE800 Ethernet switches and AC800M redundant controllers;
• Hiccup short-circuit auto-recovery: Automatically restore output after field network wiring short-circuit fault elimination, no permanent burnout of power supply and backend synchronization network modules;
• Over-temperature thermal shutdown: Automatically cut off output for self-protection when cabinet ventilation is poor, avoid chain damage to the entire controller pairing network;
• Surge suppression: Absorb grid instantaneous surge to protect sensitive Ethernet communication chips.

3.7 Modular DIN Rail Quick Maintenance Minimize Network Synchronization Downtime

Quick plug-in wiring terminals support single-unit replacement without cutting off the power of the entire control rack, greatly shorten the maintenance downtime of the controller synchronization network. Multiple LXN1604-6 modules can be freely paralleled to expand power capacity, adapt to new production line digital transformation and large-scale multi-cabinet 800xA redundant network capacity expansion projects.

4. Typical Application Scenarios for ABB 800xA Controller Synchronization Network

1. Thermal & Hydropower Plant DCS Control Cabinets: Redundant power supply for dual AC800M controllers and NE820 core Ethernet switches, guarantee turbine/boiler controller hot standby pairing and clock synchronization
2. Chemical & Petrochemical SIS Safety Redundant Network: Uninterrupted power backbone of reactor safety control redundant controller synchronization network, support RNRP fault-free switching
3. Metallurgy Smart Rolling Mill Automation: PCS6000 medium voltage drive matching 800xA auxiliary cabinet, stable power supply for production line motion controller pairing Ethernet switches
4. New Energy EV & Cement Industry 4.0 Production Lines: Rotary kiln, battery coating line intelligent control cabinet, power supply for factory-wide controller real-time synchronization communication network
5. Water Treatment Environmental Protection Automation: Multi-station distributed S800 I/O redundant control network, dedicated power source for field layer Ethernet synchronization switches

5. Original In-Stock & Global Fast Shipping Service

All ABB LXN1604-6 / 3BHL000986P7000 industrial redundant power supply modules we supply are 100% genuine original factory products, complete with sealed original carton packaging, official factory full-performance test reports, covered by a formal 12-month warranty against manufacturing defects under rated operating conditions. Our warehouse maintains abundant permanent ready stock to rapidly process urgent 800xA controller synchronization network cabinet maintenance orders and bulk procurement for global process industrial EPC automation projects. We adopt professional anti-static, shockproof and moisture-proof dedicated export packaging to protect coated circuit boards during long-distance sea and air international transportation. We cooperate with DHL/Fedex/UPS for fast worldwide delivery covering Europe, North America, Southeast Asia, the Middle East and all major process industrial zones, with one-stop customs clearance support.
Our full supporting services include pre-sales 800xA redundant controller cabinet power load calculation, dual redundant power system topology design, dual input wiring scheme consultation, plus after-sales DIN rail installation, redundancy function debugging, NE800 Ethernet switch power matching and complete ABB Ability 800xA controller pairing synchronization network overall commissioning.

Product Core Value Summary

Genuine original ABB LXN1604-6 redundant power supply is the indispensable stable power foundation of ABB 800xA redundant controller pairing and synchronization Ethernet network. Its dual redundant zero-interruption power supply, ultra-low-noise output, anti-humidity anti-corrosion and strong anti-electromagnetic interference design effectively eliminate controller synchronization collapse, hot standby pairing failure and expensive NE800 switch/AC800M controller burnout risks brought by inferior power supplies, greatly reduce unplanned control system offline downtime and long-term factory operation maintenance costs. Supported by ample spot stock, efficient global fast shipping and complete 12-month original manufacturer warranty, it is the standard matching redundant power spare component for all ABB Ability 800xA redundant controller synchronization network automation projects.

Supplementary Note: Real 800xA Ethernet Switch Model Reference

If you need the actual network switching hardware for controller pairing synchronization, select ABB official NE800 series switches: NE801 (5-port), NE810 (10-port), NE820 (19-port DIN rail), NE840 (19-port rack-mounted)ABB Group. LXN1604-6 only provides supporting stable power supply for the above switches and controllers.
