ABB LXN1604-6 (3BHL000986P7000) Redundant DIN Rail Power Supply

Stable Power Foundation for ABB Ability 800xA Communication Network & Industry 4.0 Smart Factory System 100% Original ABB Genuine Component, Full Spot In Stock, Fast Global Door-to-Door Shipping

1. Product Overview

ABB LXN1604-6, material number 3BHL000986P7000, is a Convert Select series high-power redundant switching power supply, exclusively designed for full-stack ABB Ability™ System 800xA DCS Industry 4.0 smart factory automation architecture.

Core Supporting Role for 800xA Communication Network

All network & control hardware realizing controller hot standby pairing, RNRP redundant ring communication, MES real-time data upload and production digital twin synchronization rely on this module for continuous low-noise DC power supply:

1. NE800 series managed industrial Ethernet switches (core communication switching hardware for smart factory layer 2/3 network)
2. Dual redundant AC800M PM safety controllers, BC810 CEX-bus backplane interconnection units, TP857 baseplates
3. TC811 fiber Ethernet adapters, CI communication interface modules, RB520 safety emergency stop relays
4. Workshop HMI panels, S800 smart I/O stations, robot motion control communication boards, field intelligent sensors

Smart factory workshops face dense cabinet layout, welding/ servo motor electromagnetic interference, wide temperature fluctuation, high humidity and non-stop 24/7 production demands. This power supply integrates dual redundant input, full PCB anti-corrosion conformal coating, multi-layer surge & EMC filtering and complete overvoltage/overcurrent/short-circuit protection, eliminating communication switch offline, controller clock synchronization drift and network breakdown risks caused by power quality faults. We supply brand-new sealed original ABB units with complete factory Industry 4.0 environment test reports, abundant permanent spot inventory, worldwide expedited logistics and standard 12-month manufacturer warranty.

2. Core Technical Specifications (Smart Factory 800xA Communication Network Optimized)

表格

Parameter Item	Standard Specification
Full Part Code	LXN1604-6 / 3BHL000986P7000
Rated DC Output	24.7VDC, 20A, total power 500W, ultra-low ripple ≤100mVp-p for stable Ethernet signal
Dual Redundant Input	Dual isolated independent channels: AC 85–264V universal factory mains / DC 90–350VDC UPS battery backup
Conversion Efficiency	Up to 93% peak full-load efficiency, low heat accumulation for densely packed communication switch cabinets
Operating Temperature Range	-20℃ ~ +70℃ continuous stable operation (derating required above 55℃)
Humidity & Corrosion Resistance	5%–95% RH non-condensing, full polyurethane conformal coating anti-moisture, paint mist, salt fog & weak corrosive vapor
Mechanical Standard	IEC 60068-2-6 anti-vibration, adapt to robot reciprocating vibration and production line equipment shock
Mounting Form	Standard 35mm DIN rail snap-on metal finned heat sink housing, IP20 cabinet internal protection
Redundancy Switch Mechanism	Built-in isolation decoupling diodes, microsecond seamless dual-input switchover, no external redundant diode module needed
Parallel Expansion Capacity	Multiple modules paralleled freely to build N+1 redundant power architecture for large multi-cabinet smart factory communication networks
Complete Multi-Layer Protection Suite	OVP overvoltage, OCP overcurrent, hiccup-mode auto-recovery short-circuit protection, OTP over-temperature thermal shutdown, UVP input undervoltage lockout, multi-stage EMC surge filtering
Status Indicator	Power OK green LED + dual input channel independent fault alarm light, support remote smart cabinet network operation monitoring
Dimension & Net Weight	194 × 113.6 × 138 mm, approx. 2.8kg
Certifications	CE, UL, IEC61010 industrial safety & EMC standards, fully compatible with ABB 800xA RNRP redundant communication protocol

3. Key Advantages for ABB Ability 800xA Communication & Industry 4.0 Smart Factory

3.1 Dual Redundant Input Zero Interruption Protect Smart Factory Core Communication Network

Industry 4.0 unmanned production lines cannot tolerate millisecond-level power interruption, which will cause NE800 Ethernet switches to drop offline, primary/standby controller synchronization collapse, MES production data loss and full-line automatic production halt. Two fully isolated input terminals support dual mains + UPS dual backup power supply; when one power source fluctuates, surges or fails, the module switches to backup power within microseconds without cutting power to all communication switches and redundant controllers. Avoid catastrophic production losses caused by single power supply breakdown; built-in decoupling circuit saves valuable DIN rail cabinet space without extra redundant hardware.

3.2 Ultra-Low Ripple Clean DC Power Eliminate Communication Signal Distortion & Synchronization Deviation

Industrial Ethernet switches and controller redundant synchronization circuits are extremely sensitive to voltage ripple and high-frequency noise. LXN1604-6 optimized soft-switching power conversion circuit outputs ultra-low-noise 24V DC power, suppress transient surge and high-frequency harmonic interference generated by welding robots, servo drives and large conveyor motors in smart workshops. Guarantee microsecond-level deterministic RNRP redundant ring network operation, consistent clock timestamp synchronization between primary and standby AC800M controllers, and uninterrupted real-time transmission of workshop production data to cloud digital twin platforms.

3.3 Full Conformal Coating Anti-Harsh Environment Design Long-Term Stabilize Communication Hardware

Automotive, chemical, semiconductor smart factory control cabinets contain paint mist, oil vapor, trace chemical vapor and constant high humidity; bare circuit boards easily oxidize and generate intermittent power faults, triggering periodic network packet loss and communication disconnection. The entire internal PCB is covered with industrial anti-corrosion conformal coating, forming an airtight protective film to isolate corrosive media and moisture, eliminate hidden communication instability risks and extend service life of expensive NE800 communication switches and controllers.

3.4 93% Ultra-High Efficiency Reduce Heat Load for Dense Communication Switch Cabinets

Smart factory central control cabinets are densely equipped with multiple NE800 Ethernet switches, redundant controllers and communication modules; heat accumulation easily triggers equipment over-temperature protection and network communication jitter. Ultra-high efficiency topology drastically cuts power loss and heat generation, lowers internal cabinet temperature difference to avoid condensation on communication chips, extends the full service cycle of all digital network hardware and reduces long-term factory HVAC cooling energy consumption cost.

3.5 Multi-Stage EMC Filter Resist Strong Industrial Interference Stabilize 3-Tier Factory Communication Network

Robot servo inverters, welding equipment and medium voltage drives produce massive high-frequency harmonic electromagnetic interference, which easily causes Ethernet port disconnection, production order MES data loss and remote valve/robot control failure. Integrated multi-level LC surge filtering and full metal shielding circuit effectively suppress industrial noise, guarantee stable unobstructed communication of field equipment layer, control DCS layer and factory monitoring MES three-level Ethernet network of the ABB 800xA Industry 4.0 system.

3.6 Complete OVP/OCP/Short-Circuit Hiccup Protection Prevent Communication Hardware Burnout

• OVP Overvoltage Protection: Instantly cut output when grid surge generates overvoltage, avoid breakdown of NE800 switch communication chips and controller mainboards;
• OCP Overcurrent Protection: Two-stage current limiting against robot batch startup instantaneous overload, prevent power supply and communication wiring overheating damage;
• Hiccup Short-Circuit Auto-Recovery: After field communication cable short-circuit fault removal, automatically restore output without manual power cycle reset, minimize smart factory network maintenance downtime;
• Supplementary OTP/ UVP/Surge protection: Avoid chain damage to the entire factory communication network caused by poor cabinet ventilation or unstable mains voltage.

3.7 Compact DIN Rail Modular Design Save Cabinet Space & Fast Maintenance

Smart factory control cabinets are high-cost limited-space assets; slim integrated finned metal housing minimizes DIN rail occupation area, reserving more installation space for NE800 communication switches and I/O modules. Quick plug-in wiring terminals support single-unit hot-swap replacement without full rack power cut, greatly shorten communication network maintenance downtime during smart factory capacity expansion and equipment overhaul. Multiple modules can be freely paralleled to build N+1 redundant power system to match large-scale multi-workshop 800xA digital network upgrade projects.

4. Typical Industry 4.0 Smart Factory Application Scenarios

1. Automotive OEM Welding & Assembly Smart Workshop DCS Cabinets: Redundant power supply for dual AC800M controllers and NE820 core Ethernet switches, stabilize robot synchronization communication network, resist welding arc strong electromagnetic interference
2. Semiconductor Wafer Fab Cleanroom Digital Control Racks: Anti-chemical vapor power backbone for MES wafer production data transmission NE801/NE810 communication switches, guarantee zero interruption precision process network
3. Chemical Intelligent Factory SIS Safety Communication Cabinets: Uninterrupted power supply for reactor safety interlock redundant Ethernet ring network, adapt to acid mist & high humidity corrosive environment
4. New Energy Battery Production Line Industry 4.0 Control Cabinets: Stable power source for coating/slitting equipment motion controller pairing communication switches, wide temperature adapt to baking high-temperature control rooms
5. Metallurgy Smart Rolling Mill Digital Automation Racks: Power supply for production line real-time data upload communication network, resist long-term vibration of rolling equipment

5. Original In-Stock & Global Fast Shipping Service

All ABB LXN1604-6 / 3BHL000986P7000 industrial redundant power supply modules we provide are 100% genuine original factory products, complete with sealed original carton packaging, official factory full-performance communication network compatibility test reports, covered by a formal 12-month warranty against manufacturing defects under rated operating conditions. Our warehouse maintains abundant permanent ready stock to rapidly process urgent smart factory communication cabinet maintenance orders and bulk procurement for global Industry 4.0 EPC automation projects. We adopt professional anti-static, shockproof and moisture-proof dedicated export packaging to protect coated precision circuit boards during long-distance sea and air international transportation. We cooperate with DHL/Fedex/UPS for fast worldwide delivery covering automotive, semiconductor, chemical and new energy smart factory industrial zones across Europe, North America, Southeast Asia and the Middle East, with one-stop customs clearance support.
Our full supporting services include pre-sales 800xA communication cabinet power load calculation, dual redundant power system topology design, dual input wiring scheme consultation, plus after-sales DIN rail compact installation, redundancy function debugging, NE800 Ethernet switch power matching and complete ABB Ability 800xA Industry 4.0 smart factory digital communication network overall commissioning.

Product Core Value Summary

Genuine original ABB LXN1604-6 redundant power supply is the irreplaceable reliable power backbone of ABB Ability 800xA Industry 4.0 smart factory communication network. Its dual redundant zero-interruption power supply, ultra-low-noise anti-interference output, anti-corrosion conformal coating and full multi-layer electrical protection design fully meet the strict stable operation requirements of unmanned digital factories, effectively eliminate communication network collapse, controller synchronization failure and expensive NE800 switch/AC800M controller burnout risks brought by inferior power supplies, drastically reduce unplanned smart factory production line downtime and long-term operation maintenance costs. Supported by ample spot stock, efficient global fast shipping and complete 12-month original manufacturer warranty, it is the standard matching redundant power spare component for all ABB Ability 800xA Industry 4.0 smart factory communication network automation projects.

Supplementary Reference: Genuine ABB 800xA Industrial Ethernet Communication Switch Series

If you need actual communication switching hardware for controller pairing & network synchronization, select official ABB NE800 series switchesABB Group:

• NE801: 5-port DIN rail lightly managed Ethernet switch
• NE810: 10-port DIN rail industrial managed switch
• NE820: 19-port DIN rail core industrial switch
• NE840: 19-port rack-mounted core Ethernet switch LXN1604-6 only provides stable uninterrupted 24V power supply for the above communication switches and all 800xA control hardware.
